Total Video Input: 11 with 10 active.
Total Video Outputs: 10
Total Aux Outputs: 3
SDI Rates: 270Mb, 1.5G, 3G, 6G
Total Audio Inputs: 2 x XLR. 2 x RCA.
Total Audio Outputs: 2 x XLR Program.
Timecode Connections: None
Reference Input: Tri-Sync or Black Burst.
Video Input Re-Sync: On all 10 inputs.
SDI Video Inputs: 10 x 10-bit SD/HD/Ultra HD 4K switchable. 2 channel embedded audio.
HDMI Video Input: 1 x HDMI type A. 10-bit SD/HD/Ultra HD 4K switchable. 2 channel embedded audio.
Analog Audio Outputs: 2 x XLR.
SDI Audio Outputs: 2 Ch embedded into SDI output on all outputs.
SDI Program Outputs: 2 x 10-bit SD/HD/Ultra HD 4K switchable.
HDMI Program Outputs: 1 x HDMI type A, 10-bit SD/HD/Ultra HD 4K switchable.
Down Converted SDI Program Output: 1 x 10-bit (Ultra HD 4K to HD)
SDI Preview Output: 1 x 10-bit SD/HD/Ultra HD 4K switchable.
Total Multi Views: 1
SDI Multi View Outputs: 1
HDMI Multi View Outputs: 1
Control Panel Connection: Ethernet supports 10/100/1000 BaseT. Allows direct connection between panel and chassis, or via network.
Tally Output: Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included.)
Computer Interface: 1 x USB 2.0 port.
